A vast database of over 20,000 sets of lens data
Through data refinement, we have constructed over 512 virtual lens models
During the lens marking process, automatically invoke the lens model that closely resembles the actual lens, and then utilize AI algorithms to simulate data that closely resembles the characteristics of the real lens.
Designed For an Unparalleled User Experience
High-Precision integrated chip that combines four modules of ranging, Receiving, driving and power supply into one.
AUTOFOCUS
Assistive Autofocus
The advent of MOTOR SMART has made handheld shooting more versatile and flexible
Wide-Area Focus
The motor rangefinder will automatically identify and autofocus on objects in the scanning range that are closer to the camera.
4 MODULE
High Troque Low Latency, High Precision
The latest 5.3 Bluetooth connection technology, with a control distance of up to 100 meters
Fast scanning target distance AI analysis travel data Assisted autofocus
Supporting fast charging and quick replacement, with a battery life of nearly 6-10 hours
FOCUS CONTROL
The World's Smallest Thumbwheel for Focus Control
Easy Installation Anywhere, Without Any Obstacles
The controller comes with a 1/4-inch screw and can be mounted on any equipment with a corresponding screw hole, such as kits, handles, and monitors.
REMOTE AIR RIR Large Handwheel Device
Get rid of spatial limitations, operate wirelessly and appear more confident.
Intelligent and Comprehensive
A-B Point lens limit. A-B point lens automatic operation.
Quick Lens AF Marking
After completing lens travel calibration, simply mark three positions to quickly complete the marking process and enjoy autofocus functionality.
Manual/Automatic Calibration
Using the motor button, easily start automatic lens calibration. For lenses with infinite rotation, manual calibration can also be used to set the lens travel distance
Fast AF Channel Switching
Differentiate lenses that have been AF marked using lens label stickers, switch the motor channel to match the labeled lens, and then calibrate the lens stroke to enable autofocus functionality.
The controller has a travel resolution of 16384 DPI, and the motor has a travel resolution of up to 16384 DPI per rotation, enabling low-latency response to operational commands.
Comes with a 0.8 Mod gear as standard, and additional 0.4/0.5/0.6 Mod gears can be purchased for easy compatibility with various lenses.
AF & MF Switching
All settings can be configured using a single button press
Real-time distance measurement and assisted autofocus achieved through AI algorithm
Power Light
Real-time feedback on motor power and response speed status
Channel Light
Ability to store AF data for up to five lenses
Motor Battery Life
MOTOR SMART MINI
LI-42Bx2 Battery / Endurance: 6-8 hours Supports quick disassembly
MOTOR SMART
LI-42Bx3 Battery / Endurance: 8-10 hours Supports quick disassembly
Controller Battery Life
PDL-TC-AFX
LIR2477 Battery Endurance: 8 - 10 Hours upports quick disassembly
Assistive Focus Stickers
Applying assistive focus stickers can increase LIDAR measuring distance. Users can use the provided reflective stickers or purchase their own preferred reflective stickers
Ultimate Tool for Solo Shooting
Automatic focus allows for an integrated user experience of receiving, monitoring, and controlling by a single individual
Comparison
MOTOR SAMRT MINI VS MOTOR SMART
Illuminance Performance
Motor Performance
Feature:
- Suitable for connecting with PDL-TC-AFX.
- Apply to auto/ manual control various cine lenses or SLR lenses
- Autofocus lens data mark and save, can save up to 5 lenses
- Automatically calibrated lens stroke
- Manually calibrated the lens stroke
- Motor rotation direction setting
- Motor speed setting
- Ios App control
Specifications:
Weight: 132g
Size: L 87mm * W 56mm * H 20mm
Rod clamp size: DIA 15mm
Maximum torque: 0.75Nm
Operating Voltage: 6.4V~8.4V
Temperature: +60°C;-20°C
Power supply: Li-42Bx2 recharger battery (3.7V 600mAh 2.2Wh)
Connections: Bluetooth 5.0
LiDAR scanning distance: 4m, 28 degree
Wireless working distance: Straight line - Max 100m
Package Contents:
1x Motor Smart Mini (PD-BTMP-S)
2x LI42Bx2 Battery
1x LI-42B Battery Charger
1x Hot Shoe Clamp
1x Lens gear ring
1x Micro USB Charging Cable
1x Spanner 1/4 screw Kit
1x Assistive Focus Stickers
1x 15mm Rod
1x Lens label stickers
1x Zipper Box
