Features:
- Patented anamorphic design
- 2X constant squeeze ratio
- T2 Large Aperture
- Outstanding sharpness
- Close focusing distance
- Pleasant oval bokeh
- Amber, blue & silver flare colors
- Low Focus-breathing
- User-friendly cine housing
- full-frame coverage with 1.4X extender
Specifications:
|
Focal length |
35mm |
45mm |
60mm |
85mm |
|
Aperture range |
T2.0 - T22 |
|||
|
Angle of view |
73°x34.3° |
59.9°x27° |
46.7°x20.4° |
33.9°x14.5° |
|
Image circle diameter |
25.92x21.6mm |
|||
|
Squeeze Ratio |
2X |
|||
|
Format |
Super 35 |
|||
|
Lens structure |
17 elements in 14 groups |
17 elements in 14 groups |
17 elements in 13 groups |
18 elements in 13 groups |
|
Aperture blades |
10 blades |
|||
|
Flange distance |
Arri PL: 52mm / Canon EF: 44mm |
|||
|
Focus throw |
300° |
|||
|
Aperture throw |
60° |
|||
|
Focus indicator |
Foot or meter |
|||
|
Min. focusing distance |
0.55m (1.8 ft) |
0.55m (1.8 ft) |
0.7m (2.3 ft) |
0.82m (2.7 ft) |
|
In-focus driving mode |
Manual (MF) |
|||
|
Follow focus pitch |
0.8mm |
|||
|
Filter Thread |
Ø 105mm |
|||
|
Dimensions |
About Ø 119.6*182mm |
About Ø 119.6*182mm |
About Ø 119.6*198mm |
About Ø 116*240m |
|
W eight |
About 2.4kg |
About 2.4kg |
About 2.3kg |
About 2.95kg |
|
Flare Colors |
Blue / Amber / Silver |
|||
|
Mount |
Arri PL / Canon EF (Interchangeable Canon EF bayonet is presented) |
|||
|
Price |
Single Lens: USD4,999 |
|||
